General
- Model Number
- FA507NU / FA507NV
- Series
- TUF Gaming
- Colors
- Mecha Gray
- Target Use
- Gaming / Content Creation
- Os
- Windows 11 Home
- Os Version
- 64-bit
- Warranty
- 1 Year Limited Warranty
- Price
Cpu
- Brand
- AMD
- Name
- Ryzen 7 7735HS or Ryzen 7 7435HS
- Generation
- 7000 Series
- Series
- HS (High Performance, Slim)
- Fabrication Nm
- 6nm
- Architecture
- Zen 3+
- Total Cores
- 8 Cores
- P Cores
- E Cores
- Lp E Cores
- Threads
- 16 Threads
- Base Clock Ghz
- 3.2 GHz (7735HS) or 3.1 GHz (7435HS)
- Boost Clock Ghz
- Up to 4.7 GHz (7735HS) or 4.5 GHz (7435HS)
- Cache
- 20MB Total (4MB L2 + 16MB L3)
- Tdp Tgp
- 35W - 54W (Configurable TDP)
- Ctdp
- Up to 54W
- Igpu Name
- AMD Radeon 680M
- Npu Tops
- ~10 TOPS (Ryzen AI)
- Benchmarks
- ~13,000+ (Cinebench R23 Multi-core)
Display
- Screen Size
- 15.6 inch (39.62 cm)
- Resolution
- FHD (1920 x 1080)
- Ppi
- 141 PPI
- Panel Type
- IPS-level
- Refresh Rate
- 144Hz
- Response Ms
- ~3ms (Overdrive)
- Touch
- Aspect Ratio
- 16:9
- Brightness
- 250 - 300 nits
- Contrast
- 1000:1
- Srgb
- 100% (High-end panels) or 62.5% (Entry-level panels)
- P3
- ~75%
- Adobe Rgb
- ~75%
- Delta E
- < 2.0 (on calibrated units)
- Hdr Standard
- Finish
- Anti-glare
- Screen To Body
- 80%
- Glass
- Low Blue
- Factory Calibrated
- Yes
- Vrr
- G-Sync compatible / Adaptive-Sync
Gpu
- Igpu Name
- Igpu Eu
- 2560 (RTX 4050) / 3072 (RTX 4060)
- Igpu Clock
- 2200 MHz
- Igpu Shared Mem
- Up to 8GB
- Dgpu Brand
- NVIDIA
- Dgpu Model
- GeForce RTX 4050 or RTX 4060
- Dgpu Vram Gb
- 6GB (RTX 4050) or 8GB (RTX 4060) GDDR6
- Dgpu Vram Type
- GDDR6
- Dgpu Bus
- 96-bit (4050) / 128-bit (4060)
- Dgpu Tgp
- Up to 140W (115W + 25W Dynamic Boost)
- Dgpu Boost
- Dgpu Cores
- Rt
- Yes, support for Ray Tracing
- Upscaling
- DLSS 3.5
- Mux
- Yes (with NVIDIA Advanced Optimus)
- Hybrid
Ram
- Size Gb
- 16GB (8GB x 2)
- Type
- DDR5
- Speed
- 4800 MT/s
- Bus
- Channels
- Dual Channel
- Upgradeable
- Fully Upgradeable
- Slots
- 2x SO-DIMM slots
- Max Ram
- Up to 32GB (officially) or 64GB (unofficially)
- Ecc
Storage
- Size
- 512GB or 1TB
- Type
- PCIe 4.0 NVMe M.2 SSD
- Form Factor
- M.2 2280
- Interface
- NVMe PCIe 4.0
- Read
- ~5000 MB/s
- Write
- ~3500 MB/s
- Iops
- M2 Slots
- 2x M.2 Slots (One occupied, one free)
- Bay 25
- Upgradeable
- Raid
- RAID 0 supported
Battery
- Capacity Wh
- 90Wh
- Cells
- 4-cell Li-ion
- Chemistry
- Life Hrs
- 12+ hours (Video Playback)
- Charge W
- Port Type
- Usbc Pd
- Fast Charge
- 0% to 50% in 30 mins
- Charger W
- 240W AC Adapter
- Charger Weight
- ~600g
- Reverse
Cooling
- Type
- 84-blade Arc Flow Fans with 4 exhaust vents and 5 heat pipes
- Fans
- Heat Pipes
- 5 Heat pipes
- Fan Rpm
- Thermal Modes
- Silent, Performance, Turbo
- Liquid Metal
- Vapor
- Egpu
- Yes (via USB4)
Keyboard
- Layout
- Full-size island-style
- Numpad
- Yes
- Travel Mm
- 1.7mm
- Switch Type
- Backlight
- 1-Zone RGB
- Backlight Zones
- Ghosting
- Spill
- Fp
- Touchpad Size
- Large
- Touchpad Type
- Precision
- Glass Touchpad
- Stylus
- Touchscreen
- Dedicated Keys
Webcam
- Resolution
- 720P HD camera
- Fps
- 30 FPS
- Ir
- Face Recognition
- Shutter
- Mic Count
- 2 Microphones
- Mic Type
- AI Noise Canceling
- Voice Assistant
- Cortana/Alexa
Audio
- Speakers
- 2-speaker system
- Watts
- Brand
- Dolby
- Dolby Atmos
- Hires
- Jack
- Line In
Ports
- Usb A
- 2x USB 3.2 Gen 1 Type-A
- Usb C
- 1x Type C USB 4 (DP support) + 1x USB 3.2 Gen 2 Type-C (DP/PD/G-Sync)
- Thunderbolt
- Hdmi
- 1x HDMI 2.1 FRL
- Dp
- Sd
- Jack35
- Rj45
- Yes (Gigabit)
- Lock
- Kensington
- Dock
- Yes
- Ext Display
- Up to 3
Wireless
- Wifi
- Wi-Fi 6E (802.11ax)
- Bands
- Dual-band
- Max Throughput
- 2.4 Gbps
- Mimo
- 2x2
- Wifi Chip
- Bt
- Bluetooth 5.3
- Bt Profiles
- Nfc
- Wwan
- Esim
- Gps
- Uwb
Build
- Dimensions
- 358 x 254 x 20mm (approx.)
- Weight
- 2.20 kg (4.85 lbs)
- Lid
- Aluminum
- Base
- Plastic
- Hinge
- Convertible
- Hinge Rating
- Mil
- Yes (Tested for drops, vibration, humidity, and extreme temperatures)
- Ip
- Chassis
Security
- Fingerprint
- Hello
- Tpm
- Kensington
- Yes
- Smartcard
- Bios
- Yes
- Kill Switch
- Sed
- Yes
Sensors
- Ambient
- Accel Gyro
- Hall
- Proximity
- Pressure
Software
- Pre Os
- Windows 11 Home
- Bloatware
- Moderate (MyASUS, Armoury Crate)
- Os Updates
- standard Windows
- Ai
- AI Noise Canceling / DLSS
- Copilot Key
- Yes (2024 Models)
- Suite
- Office Home & Student
- App Store
- Microsoft Store
Inbox
- Charger
- Yes, 240W
- Cable
- Power Cable
- Dongle
- Sleeve
- TUF Backpack (often included)
- Mouse
- Docs
- Quick Start Guide
- Stylus
